MNm45
Jet Pumps
Jet Pump
About this item
WATER PUMP
- Special anti-rest treatment for cast iron pump body and support
- Brass impeller
- AISI 304 shaft
- Maximum liquid temperature: +60°C
- Maximum suction:
- Product code: MNm45
- HP: 0.75
- VOLTAGE: 220-240
- Phase: single phase motor
- FREQUENCY (Hz): 60
- PIPE SIZE: 1” × 1”
- MAX.HEAD (Hmax) : 49 m
- MAX.DELIVERY (Qmax) : l/min
Availability : 10+ in stock
Warranty : 24 Months
Free 2.0 year warranty - Terms & Conditions
Add more:
Price:
MNm45 (0.75 HP), 220-240V, 60Hz, 1″×1″
Application
KANZO MNm45 (0.75 HP) can transfer clean water or other liquids like water in physical and chemical properties. It’s suitable for lifting water from the well, sprinkling irrigation in garden, pressure boosting of running water and supporting equipment etc.
Pump Features
- Special anti-rest treatment for cast iron pump body and support
- Brass impeller
- AISI 304 shaft
- Maximum liquid temperature: +60°C
- Maximum suction:
Motor Features
- Single phase
- Heavy duty continuous work
- Low noise& Long-life bearing
- Built-in thermal protecter for single phase motor
- Insulation class: F
- Protection class: IP×4
- Maximum ambient temperature: +50°C
- Cooling: External ventilation
Operating Conditions
- Continuous duty
- pH: 6.5 to 8.5
Advantages
- Pump body with installation foot set
- High pressure
- Larger flow, good self-priming time
- Compacted design, easy installation and maintenance
- Low noise
- High suction with short time
- Different impeller materials configuration
Identification codes
General
- Brand: KANZO Pumps
- Model number:
- Type: Jet
- Usage: Domestic
- Color: Grey& yellowish orange
- Material:
- Flow rate:
- Total head: 49 m
- MAX.DELIVERY (Qmax) : l/min
- Inlet size: 1"
- Outlet size: 1"
- Country of origin: Made in China (ITALIAN STANDARD)
Power features
- Phase: Single Phase Motor
- Thermal overload protecter: yes
- Power Supply: 220-240
- Power Rating:
- Motor power: 0.75HP
Additional Features
- Corrosion Resistant: yes
- Other features: NILL
Dimensions
- Weight:
- Net Quantity: 1 Count
- Included Components:
Warranty
- Warranty: 2 years
- Service Type: NILL
- Covered in warranty: Yes
- Not covered in warranty: NILL
Technical data
Dimensions
Hydraulic performance Curves
Materials Table
Packaging Information
